ASI 8203 – Compact Folding Shower Seat – Solid Phenolic
- Phenolic Top Color is IVORY
- Compact Rectangular Phenolic Fold-up Shower Seat
- Shall have all metal parts fabricated of 18-8 alloy type 304 stainless steel.
- Seat frame and support legs 1″ dia and 1-1/4″ square x 18 gauge with 3/16″ thick mounting flanges.
- All exposed surfaces shall have satin finish.
- Structural assembly shall be of welded construction, exposed edges and corners shall be radiused.
- Seat shall be 5/16″ (8) thick solid phenolic with white color top and bottom surfaces and shall have black edges.
- Support arm shall fold up when in retracted position to provide low profile against wall.
- No extra fittings shall be required to retain seat in storage position.
- Guide bracket shall control seat lowering into operating position.
- Unit shall satisfy ADA Accessibility Guidelines when mounted properly.
- Seat Material: One piece phenolic, ivory colored. Slotted for drainage.
- Frame Material: 304 Satin finish, stainless steel.
- Weight: 13.0 lbs.
- Load Capacity: Rated up to 500 lbs when properly installed.
- Height Open: 17″ to 19″
- Height Closed: 28 9/16″ to 30 9/16″
